Part No.
Waveguide
Size 1
Flange 1
Type
Flange 1
Designation
Flange 2
Type
Waveguide
Size 2
Flange 2
Designation
- Frequency range of 5.85 GHz to 110 GHz across 14 bands
- Waveguide sizes ranging from WR-137 (5.85 GHz) to WR-10 (110 GHz)
- Smooth transition between different waveguide size with minimum loss
- VSWR as low as 1.08:1
- Rugged gold plated or painted brass construction
- UG-style square and round flanges or CPRG style flanges or UBR style flange
All in stock and ready for same-day shipping!
▼ Click on the links below for more details
Waveguide to Waveguide Transitions
Part No.
Waveguide
Size 1
Flange 1
Designation
Flange 1
Type
Waveguide
Size 2
Flange 2
Designation
Flange 2
Type
 |
PE-W10TS12001 | WR-10 |
UG-387/U-Mod |
Round Cover |
WR-12 |
UG-387/U |
Round Cover |
|
 |
PE-W10TS15001 | WR-10 |
UG-387/U-Mod |
Round Cover |
WR-15 |
UG-385/U |
Round Cover |
|
 |
PE-W10TS19001 | WR-10 |
UG-387/U-Mod |
Round Cover |
WR-19 |
UG-383/U-Mod |
Round Cover |
|
 |
PE-W12TS15001 | WR-12 |
UG-387/U |
Round Cover |
WR-15 |
UG-385/U |
Round Cover |
|
 |
PE-W15TS22001 | WR-15 |
UG-385/U |
Round Cover |
WR-22 |
UG-383/U |
Round Cover |
|
 |
PE-W15TS19001 | WR-15 |
UG-385/U |
Round Cover |
WR-19 |
UG-383/U-Mod |
Round Cover |
|
 |
PE-W19TS28001 | WR-19 |
UG-383/U-Mod |
Round Cover |
WR-28 |
UG-599/U |
Square Cover |
|
 |
PE-W19TS22001 | WR-19 |
UG-383/U-Mod |
Round Cover |
WR-22 |
UG-383/U |
Round Cover |
|
 |
PE-W22TS42001 | WR-22 |
UG-383/U |
Round Cover |
WR-42 |
UG-595/U |
Square Cover |
|
 |
PE-W22TS28001 | WR-22 |
UG-383/U |
Round Cover |
WR-28 |
UG-599/U |
Square Cover |
|
 |
PE-W28TS51001 | WR-28 |
UG-599/U |
Square Cover |
WR-51 |
UBR-180/U-Mod |
UBR |
|
 |
PE-W28TS42001 | WR-28 |
UG-599/U |
Square Cover |
WR-42 |
UG-595/U |
Square Cover |
|
 |
PEWTS1010 | WR-34 |
UG-1530/U |
Square Cover |
WR-28 |
UG-599/U |
Square Cover |
|
 |
PEWTS1009 | WR-42 |
UG-595/U |
Square Cover |
WR-34 |
UG-1530/U |
Square Cover |
|
 |
PEWTS1008 | WR-51 |
Square Cover |
WR-42 |
UG-595/U |
Square Cover |
||
 |
PEWTS1007 | WR-62 |
UG-1665/U |
Square Cover |
WR-51 |
Square Cover |
||
 |
PEWTS1006 | WR-75 |
Square Cover |
WR-62 |
UG-1665/U |
Square Cover |
||
 |
PEWTS1005 | WR-90 |
CPR-90G |
CPRG |
WR-75 |
Square Cover |
||
 |
PEWTS1004 | WR-90 |
UG-39/U |
Square Cover |
WR-75 |
Square Cover |
||
 |
PEWTS1003 | WR-112 |
CPR-112G |
CPRG |
WR-90 |
CPR-90G |
CPRG |
|
 |
PEWTS1002 | WR-112 |
UG-51/U |
Square Cover |
WR-90 |
UG-39/U |
Square Cover |
|
 |
PEWTS1001 | WR-137 |
CPR-137G |
CPRG |
WR-112 |
CPR-112G |
CPRG |
|
 |
PEWTS1000 | WR-137 |
UG-344/U |
Round Cover |
WR-112 |
UG-51/U |
Square Cover |
|
Waveguide to Waveguide Transitions
Our family of waveguide transitions operate from 5.85 to 110 GHz across fourteen frequency bands and provide a smooth transition between these different waveguide sizes with minimal loss and VSWR as low as 1.08:1. These waveguide transitions, also referred to as waveguide adapters, are widely used in high power wireless applications such as instrumentation, test benches, SATCOM, MILCOM, radar, and telecom where signal strength and integrity are critical. In systems that utilize varying waveguide sizes and frequencies, it is necessary to have the proper transitions that result in the least amount of signal loss. Pasternack now carries a broad portfolio of in-stock waveguide transitions that are constructed of rugged gold plated or painted brass depending on the model. These waveguide transitions are offered with UG-style square and round flanges, CPRG-style flanges or UBR-style flanges.
