WR-15 導波管ホーンアンテナ、動作範囲 58 GHz 〜 63 GHz 、公称 0 dBi ゲイン、UG-387/U 円形フランジ

製品ID: PE-W15A001
終息品
代替品PEW15A001.

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
Waveguide SizeWR-15
Flange SizeUG-387/U
Direction TypeOmni Directional
PolarizationVertical
Frequency, Min58 GHz
Frequency, Max63 GHz
Beam Width, 3dB V360
Beam Width, 3dB H35

Description

WR-15 Waveguide Horn Antenna Operating From 58 GHz to 63 GHz With a Nominal 0 dBi Gain With UG-387/U Flange

PE-W15A001 WR-15 waveguide horn antenna is also known as a WR-15 horn antenna. This WR-15 waveguide horn antenna has a dB nominal gain and a ug-387/u flange. Our dB WR-15 horn antenna has a minimum frequency of 58 GHz and a maximum frequency of 63 GHz.

WR-15 horn antenna PE-W15A001 has a vertical beam width of 360 and horizontal of 35 degrees at 3 dB. This WR-15 waveguide horn antenna with dB is part of over 40,000 RF, microwave and millimeter wave components available from Pasternack. Our WR-15 horn antenna can ship worldwide the same day as it is purchased as with our other available RF parts.
