Mini SMP オス～ Mini SMP オスケーブル, PE-P086HF 同軸

製品ID: PE3W17715

長さ

標準長

カスタム長

*長さは0.25インチまたはcm単位で指定できます

データ
シート

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1	Mini SMP
Connector Gender 1	Male
Connector Polarity 1	Standard
Connector Angle 1	Straight
Connector Mount Method 1	None
Connector Impedance 1	50 Ohm
Connector Series 2	Mini SMP
Connector Gender 2	Male
Connector Polarity 2	Standard
Connector Angle 2	Straight
Connector Mount Method 2	None
Connector Impedance 2	50 Ohm
RF Cable Part Number	PE-P086HF
RF Cable Type	PE-P086HF
RF Cable Impedance	50 Ohm

Description

Click on the below images to access KitBOM product pages:


PE45540	PE-P086HF	PE45540	KitBOM Datasheet

Mini SMP Male to Mini SMP Male Cable Using PE-P086HF Coax

PE3W17715 is a Mini SMP male to Mini SMP male cable using PE-P086HF coax. This Pasternack Mini SMP male to Mini SMP male cable assembly uses a 50 Ohm Mini SMP for connector 1 and a 50 Ohm Mini SMP for connector 2.

Our male Mini SMP to male Mini SMP cable assembly uses a flexible cable type that is 50 Ohm. Pasternack PE3W17715 Mini SMP male to Mini SMP male cable assembly is constructed with PE-P086HF coax.
