75 Ω N オス コネクタ、クランプ/はんだ接続、RG6

製品ID: PE4507

数量別価格

数量単価
1-24¥7,428
25-49¥7,057
50-99¥6,685
100-249¥6,388
250+Call

消費税込単価
数量:
在庫数:1,011
消費税込単価

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
PolarityStandard
Connector SeriesN
Connector GenderMale
Impedance75 Ohm
Body StyleStraight
Attachment MethodClamp/Solder
Mount MethodNone
Interface Type 1RG6

Description

75 Ohm N Male Connector Clamp/Solder Attachment for RG6

PE4507 type N male coaxial connector has an interface type of RG6 and a 75 Ohm impedance. Pasternack type N male connector uses shield/contact clamp/solder as an attachment method.

The Pasternack type N male coaxial connector has a PTFE dielectric type. The Pasternack type N coaxial connector has a brass body with nickel plating. Our PE4507 type N connector uses brass contact. This N type male coaxial RF connector is RoHS and REACH compliant.

This Pasternack male type N connector will ship the same day as purchased. Our N type male connector is part of over 40,000 RF, microwave and millimeter wave components in stock for worldwide shipment. We also build custom type N connector cable assemblies that will ship the same day as well.
