SSMC プラグ〜 SMB ジャックバルクヘッドケーブル、RG178 同軸

製品ID: PE3W08023

長さ

標準長

カスタム長

*長さは0.25インチまたはcm単位で指定できます

データ
シート

Key Specifications

Key Specifications (Click on Data Sheet Above for Additional Details).
Connector Series 1	SSMC
Connector Gender 1	Plug
Connector Polarity 1	Standard
Connector Angle 1	Straight
Connector Mount Method 1	None
Connector Impedance 1	50 Ohm
Connector Series 2	SMB
Connector Gender 2	Jack
Connector Polarity 2	Standard
Connector Angle 2	Straight
Connector Mount Method 2	Bulkhead
Connector Impedance 2	50 Ohm
RF Cable Part Number	RG178B/U
RF Cable Type	RG178
RF Cable Impedance	50 Ohm

Description

Click on the below images to access KitBOM product pages:


PE45490	RG178B/U	PE4364	KitBOM Datasheet

SSMC Plug to SMB Jack Bulkhead Cable Using RG178 Coax

PE3W08023 is a SSMC plug to SMB jack bulkhead cable using RG178 coax. This Pasternack SSMC plug to SMB jack bulkhead cable assembly uses a 50 Ohm SSMC for connector 1 and a 50 Ohm SMB for connector 2.

Our plug SSMC to jack SMB bulkhead cable assembly uses a flexible cable type that is 50 Ohm. Pasternack PE3W08023 SSMC plug to SMB jack bulkhead cable assembly is constructed with RG178 coax.
